Create a Local Yum Repository Using an ISO Image on Exadata Database Machine
You want to install some packages on the Exadata Compute nodes running Oracle Enterprise Linux and you don’t have internet access. In those cases you can create a local YUM repository using DVD Image. You simply download the DVD Image on the Desktop/Laptop where you have the internet access, copy it to the server and mount it.
In this article we will demonstrate how create a Local YUM Repository using ISO Image on Exadata Database Machines.
Prerequisites
Steps to create a Local YUM Repository using ISO Image on Exadata Database Machines
Step 1: Download Oracle Linux DVD Image from the Oracle Software Delivery Cloud at http://edelivery.oracle.com/linux
Here I am downloading:
V860937-01.iso Oracle Linux 6 Update 9 for x86 64 bit, 3.8 GB
Step 2: Copy the DVD image to the server to a staging directory using Winscp
Create a staging directory on the server
[root@dm01db01 ~]# mkdir -p /u01/app/oracle/software/ISO
Use Winscp to copy the ISO Image to the server
[root@dm01db01 ~]# ls -l /u01/app/oracle/software/ISO
total 3953672
-rw-r–r– 1 root root 4048551936 Mar 20 04:18 V860937-01.iso
Step 3: Create a mount point, for example /mnt/OEL6.9, and mount the DVD image on it.
[root@dm01db01 ~]# mkdir -p /mnt/OEL6.9
[root@dm01db01 ~]# ls -l /mnt/OEL6.9
total 0
[root@dm01db01 ~]# mount -o loop,ro /u01/app/oracle/software/ISO/V860937-01.iso /mnt/OEL6.9
[root@dm01db01 ~]# df -h /mnt/OEL6.9
Filesystem Size Used Avail Use% Mounted on
/u01/app/oracle/software/ISO/V860937-01.iso
3.8G 3.8G 0 100% /mnt/OEL6.9
[root@dm01db01 ~]# cd /mnt/OEL6.9
[root@dm01db01 OEL6.9]# ls -l
total 1686
drwxr-xr-x 3 root root 2048 Mar 24 2017 EFI
-rw-r–r– 1 root root 8529 Mar 24 2017 EULA
-rw-r–r– 1 root root 8529 Mar 24 2017 eula.en_US
-rw-r–r– 1 root root 3334 Mar 24 2017 eula.py
-rw-r–r– 1 root root 18390 Mar 24 2017 GPL
drwxr-xr-x 3 root root 2048 Mar 24 2017 HighAvailability
drwxr-xr-x 3 root root 2048 Mar 24 2017 images
drwxr-xr-x 2 root root 2048 Mar 24 2017 isolinux
drwxr-xr-x 3 root root 2048 Mar 24 2017 LoadBalancer
-rw-r–r– 1 root root 98 Mar 24 2017 media.repo
drwxr-xr-x 2 root root 716800 Mar 24 2017 Packages
-rw-r–r– 1 root root 7193 Mar 24 2017 README-en
-rw-r–r– 1 root root 6016 Mar 24 2017 README-en.html
-rw-r–r– 1 root root 81004 Mar 24 2017 RELEASE-NOTES-en
-rw-r–r– 1 root root 227548 Mar 24 2017 RELEASE-NOTES-en.html
-rw-r–r– 1 root root 81004 Mar 24 2017 RELEASE-NOTES-x86_64-en
-rw-r–r– 1 root root 227548 Mar 24 2017 RELEASE-NOTES-x86_64-en.html
-rw-r–r– 1 root root 81004 Mar 24 2017 RELEASE-NOTES-x86-en
-rw-r–r– 1 root root 227548 Mar 24 2017 RELEASE-NOTES-x86-en.html
lrwxrwxrwx 1 root root 15 Mar 24 2017 repodata -> Server/repodata
drwxr-xr-x 3 root root 2048 Mar 24 2017 ResilientStorage
-rw-r–r– 1 root root 1011 Mar 24 2017 RPM-GPG-KEY
-rw-r–r– 1 root root 1011 Mar 24 2017 RPM-GPG-KEY-oracle
drwxr-xr-x 3 root root 2048 Mar 24 2017 ScalableFileSystem
drwxr-xr-x 4 root root 2048 Mar 24 2017 Server
-rw-r–r– 1 root root 108 Mar 24 2017 supportinfo
-r–r–r– 1 root root 6517 Mar 24 2017 TRANS.TBL
drwxr-xr-x 3 root root 2048 Mar 24 2017 UEK4
Step 4: Add an entry to the /etc/fstab file, this will to auto mount the DVD image after a reboot.
/u01/app/oracle/software/ISO/V860937-01.iso /mnt/OEL6.9 iso9660 loop,ro 0 0
[root@dm01db01 ~]# vi /etc/fstab
[root@dm01db01 ~]# cat /etc/fstab
LABEL=DBSYS / ext4 defaults 1 1
LABEL=BOOT /boot ext4 defaults,nodev 1 1
LABEL=DBORA /u01 ext4 defaults,nodev 1 1
tmpfs /dev/shm tmpfs defaults,size=258341m 0
devpts /dev/pts devpts gid=5,mode=620 0 0
sysfs /sys sysfs defaults 0 0
proc /proc proc defaults 0 0
LABEL=SWAP swap swap defaults 0 0
/u01/app/oracle/software/ISO/V860937-01.iso /mnt/OEL6.9 iso9660 loop,ro 0 0
Step 5: Navigate to /etc/yum.repos.d directory, you can edit the existing repository files public-yum-ol6.repo or create a new repo file such as ULN-base.repo, and disable all entries by setting enabled=0.
[root@dm01db01 ~]# cd /etc/yum.repos.d
[root@dm01db01 yum.repos.d]# ls -l
total 20
-rw-r—– 1 root root 291 Mar 31 22:43 Exadata-computenode.repo
-r–r—– 1 root root 896 Jan 26 06:19 Exadata-computenode.repo.sample
-rw-r–r– 1 root root 7299 Mar 20 05:57 public-yum-ol6.repo
Here I am going to create the OL69.repo repository file and add the entries
[root@dm01db01 yum.repos.d]# vi OL69.repo
[root@dm01db01 yum.repos.d]# cat OL69.repo
[OL69]
name=Oracle Linux 6.9 x86_64
baseurl=file:///mnt/OEL6.9
gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY
gpgcheck=1
enabled=1
Step 7: Perform YUM Cache cleanup as below
[root@dm01db01 yum.repos.d]# yum clean all
Cleaning repos: OL69
Cleaning up Everything
Step 8: Perform a test to ensure you can access yum repository
[root@dm01db01 yum.repos.d]# yum repolist
OL69 | 3.7 kB 00:00 …
OL69/primary_db | 3.1 MB 00:00 …
repo id repo name status
OL69 Oracle Linux 6.9 x86_64 3,860
repolist: 3,860
Conclusion
In this article we have learned how to create local YUM repository using DVD ISO Image on Exadata Database Machine. Configuring a local YUM repository comes handy when you want to install packages on the server and you don’t have internet access from the server.
