Overview:

Oracle Recovery Manager
(RMAN) provides a comprehensive foundation for efficiently backing up and
recovering the Oracle databases, it provides a common interface, via command line and
Enterprise Manager, for backup tasks across different host operating systems, automates administration of your
backup strategies.

   In this scenario we have different database name and different
directory structure. And we are transforming the directory structure in pfile
itself, then no need to give extra parameters in rman duplicate command.

Target (source)
details

Database Name
Prod
Hostname
Netsoftmate
Ip Address
172.16.110.18
OS
Linux
Version
x86_64
Datafile Location
/data2/prod
Backup Location
/backup/rman_backup

Destination details

Database Name
Cipfile
Hostname
Netsoftmate1
Ip Address
172.16.110.16
OS
Linux
Version
x86_64
Datafile Location
/data2/cipfile
Backup Location
/backup/rman_backup

Prerequisites

Password file from target database.

Sqlnet.ora should have correct parameters.

Target database should be running through pfile or
spfile.

Auxiliary instance should be start with pfile in nomount
stage.
Steps on target (source) server
1. Set Oracle sid on which backup will perform.

[oracle@Netsoftmate dbs]$ hostname

Netsoftmate

[oracle@Netsoftmate dbs]$ export ORACLE_SID=prod

2. Connect to target instance via RMAN.

[oracle@Netsoftmate dbs]$ rman target sys/oracle

Recovery Manager: Release 11.2.0.1.0 – Production on
Mon Apr 13 10:13:01 2015

Copyright (c) 1982, 2009, Oracle and/or its
affiliates.  All rights reserved.

connected to target
database: PROD (DBID=284539893)

RMAN>

 3. Issue the following command to initiate backup. Before issue the backup command check the backup location is sat correctly.

RMAN> show all;

using target database control file instead of
recovery catalog

RMAN configuration parameters for database with
db_unique_name PROD are:

CONFIGURE RETENTION POLICY TO REDUNDANCY 1; # default

CONFIGURE BACKUP OPTIMIZATION OFF; # default

CONFIGURE DEFAULT DEVICE TYPE TO DISK; # default

CONFIGURE CONTROLFILE AUTOBACKUP ON;

CONFIGURE CONTROLFILE AUTOBACKUP FORMAT FOR DEVICE
TYPE DISK TO ‘/backup/rman_backup/controlfile_%F’;

CONFIGURE DEVICE TYPE DISK PARALLELISM 1 BACKUP TYPE
TO BACKUPSET; # default

CONFIGURE DATAFILE BACKUP COPIES FOR DEVICE TYPE DISK
TO 1; # default

CONFIGURE ARCHIVELOG BACKUP COPIES FOR DEVICE TYPE
DISK TO 1; # default

CONFIGURE CHANNEL DEVICE TYPE DISK FORMAT   ‘/backup/rman_backup/db_arch_%U.bkp’;

CONFIGURE MAXSETSIZE TO UNLIMITED; # default

CONFIGURE ENCRYPTION FOR DATABASE OFF; # default

CONFIGURE ENCRYPTION ALGORITHM ‘AES128’; # default

CONFIGURE COMPRESSION ALGORITHM ‘BASIC’ AS OF RELEASE
‘DEFAULT’ OPTIMIZE FOR LOAD TRUE ; # default

CONFIGURE ARCHIVELOG DELETION POLICY TO NONE; #
default

CONFIGURE SNAPSHOT CONTROLFILE NAME TO
‘/data2/app/oracle/product/11.2.0/dbs/snapcf_prod.f’; # default

RMAN> list backup;

specification does not match any backup in the
repository

 4. Initiate Backup.

RMAN> backup database plus archivelog;

Starting backup at 13-APR-15

current log archived

allocated channel: ORA_DISK_1

channel ORA_DISK_1: SID=15 device type=DISK

channel ORA_DISK_1: starting archived log backup set

channel ORA_DISK_1: specifying archived log(s) in
backup set

input archived log thread=1 sequence=153 RECID=149
STAMP=876910536

channel ORA_DISK_1: starting piece 1 at 13-APR-15

channel ORA_DISK_1: finished piece 1 at 13-APR-15

piece
handle=/backup/rman_backup/db_arch_2uq495u9_1_1.bkp tag=TAG20150413T101536
comment=NONE

channel ORA_DISK_1: backup set complete, elapsed
time: 00:00:01

Finished backup at 13-APR-15

Starting backup at 13-APR-15

using channel ORA_DISK_1

channel ORA_DISK_1: starting full datafile backup set

channel ORA_DISK_1: specifying datafile(s) in backup
set

input datafile file number=00001
name=/data2/prod/system01.dbf

input datafile file number=00002
name=/data2/prod/sysaux01.dbf

input datafile file number=00005
name=/data2/prod/example01.dbf

input datafile file number=00003
name=/data2/prod/undotbs01.dbf

input datafile file number=00006
name=/data2/prod/data01.dbf

input datafile file number=00004
name=/data2/prod/users01.dbf

input datafile file number=00007
name=/data2/prod/test01.dbf

input datafile file number=00008
name=/data2/prod/tools01.dbf

channel ORA_DISK_1: starting piece 1 at 13-APR-15

channel ORA_DISK_1: finished piece 1 at 13-APR-15

piece handle=/backup/rman_backup/db_arch_2vq495ua_1_1.bkp
tag=TAG20150413T101538 comment=NONE

channel ORA_DISK_1: backup set complete, elapsed
time: 00:00:55

Finished backup at 13-APR-15

Starting backup at 13-APR-15

current log archived

using channel ORA_DISK_1

channel ORA_DISK_1: starting archived log backup set

channel ORA_DISK_1: specifying archived log(s) in
backup set

input archived log thread=1 sequence=154 RECID=150
STAMP=876910594

channel ORA_DISK_1: starting piece 1 at 13-APR-15

channel ORA_DISK_1: finished piece 1 at 13-APR-15

piece handle=/backup/rman_backup/db_arch_30q49603_1_1.bkp
tag=TAG20150413T101635 comment=NONE

channel ORA_DISK_1: backup set complete, elapsed
time: 00:00:01

Finished backup at 13-APR-15

Starting Control File Autobackup at 13-APR-15

piece handle=/backup/rman_backup/controlfile_c-284539893-20150413-00
comment=NONE

Finished Control File Autobackup at 13-APR-15

 5. List out the backups

RMAN> list backup;

List of Backup Sets

===================

BS Key
Size       Device Type Elapsed
Time Completion Time

——- ———- ———– ————
—————

32
3.36M      DISK        00:00:00     13-APR-15

        BP Key:
32   Status: AVAILABLE  Compressed: NO  Tag: TAG20150413T101536

        Piece
Name: /backup/rman_backup/db_arch_2uq495u9_1_1.bkp

  List of
Archived Logs in backup set 32

  Thrd Seq     Low SCN
Low Time  Next SCN   Next Time

  —- ——-
———- ——— ———- ———

  1    153
5172938    13-APR-15 5176490    13-APR-15

BS Key  Type LV
Size       Device Type Elapsed Time
Completion Time

——- —- — ———- ———– ————
—————

33
Full    1.11G      DISK        00:00:54     13-APR-15

        BP Key:
33   Status: AVAILABLE  Compressed: NO  Tag: TAG20150413T101538

        Piece
Name: /backup/rman_backup/db_arch_2vq495ua_1_1.bkp

  List of
Datafiles in backup set 33

  File LV Type
Ckp SCN    Ckp Time  Name

  —- — —-
———- ——— —-

  1       Full 5176498    13-APR-15 /data2/prod/system01.dbf

  2       Full 5176498    13-APR-15 /data2/prod/sysaux01.dbf

  3
Full 5176498    13-APR-15
/data2/prod/undotbs01.dbf

  4       Full 5176498    13-APR-15 /data2/prod/users01.dbf

  5       Full 5176498    13-APR-15 /data2/prod/example01.dbf

  6       Full 5176498    13-APR-15 /data2/prod/data01.dbf

  7       Full 5176498    13-APR-15 /data2/prod/test01.dbf

  8       Full 5176498    13-APR-15 /data2/prod/tools01.dbf

BS Key
Size       Device Type Elapsed
Time Completion Time

——- ———- ———– ————
—————

34
9.00K      DISK        00:00:00
13-APR-15

        BP Key:
34   Status: AVAILABLE  Compressed: NO  Tag: TAG20150413T101635

        Piece
Name: /backup/rman_backup/db_arch_30q49603_1_1.bkp

  List of
Archived Logs in backup set 34

  Thrd Seq     Low SCN
Low Time  Next SCN   Next Time

  —- ——-
———- ——— ———- ———

  1    154
5176490    13-APR-15 5176531    13-APR-15

BS Key  Type LV
Size       Device Type Elapsed Time
Completion Time

——- —- — ———- ———– ————
—————

35
Full    9.52M      DISK        00:00:02     13-APR-15

        BP Key:
35   Status: AVAILABLE  Compressed: NO  Tag: TAG20150413T101636

        Piece
Name: /backup/rman_backup/controlfile_c-284539893-20150413-00

  Control File
Included: Ckp SCN: 5176543      Ckp time:
13-APR-15

RMAN>

 6. Create pfile and copy to destination server.

SQL> create
pfile=’/backup/rman_backup/initprod.ora’ from spfile;

File created.

[oracle@Netsoftmate dbs]$ scp initprod.ora
oracle@172.16.110.16:/data1/oracle11g/product/dbs/initcipfile.ora

oracle@172.16.110.16’s password:

initprod.ora
100% 1169     1.1KB/s   00:00

 Before start scp/ftp to destination server create
directory structure to accommodate Rman backup on destination server.

[oracle@Netsoftmate1 prod]$ mkdir -p
/backup/rman_backup/

7. Copy rman backup from target to destination server.

RMAN> exit

Recovery Manager complete.

[oracle@Netsoftmate dbs]$ cd /backup/rman_backup/

[oracle@Netsoftmate rman_backup]$ ls -lrt

total 1176020

-rw-r—–. 1 oracle dba    3526656 Apr 13 10:15
db_arch_2uq495u9_1_1.bkp

-rw-r—–. 1 oracle dba 1190690816 Apr 13 10:16
db_arch_2vq495ua_1_1.bkp

-rw-r—–. 1 oracle dba       9728 Apr 13 10:16
db_arch_30q49603_1_1.bkp

-rw-r—–. 1 oracle dba    9994240 Apr 13 10:16
controlfile_c-284539893-20150413-00

[oracle@Netsoftmate rman_backup]$ scp *
oracle@172.16.110.16:/backup/rman_backup/

oracle@172.16.110.16’s password:

controlfile_c-284539893-20150413-00
100% 9760KB   9.5MB/s   00:01

db_arch_2uq495u9_1_1.bkp                                                                                                                                           100%
3444KB   3.4MB/s   00:00

db_arch_2vq495ua_1_1.bkp
                                                                   100%
1136MB  11.1MB/s   01:42

db_arch_30q49603_1_1.bkp
    100% 9728     9.5KB/s
00:00


Steps on destination server
8. Create new directory structure.

[oracle@Netsoftmate1 dbs]$ mkdir -p /data2/cipfile




9. Edit the pfile.

[oracle@Netsoftmate1 dbs]$ vi initcipfile.ora




Here we have modified the pfile by adding these
parameters as follows.

*.db_name=’cipfile’

*.control_files=’/data2/cipfile/control01.ctl’,’/data2/cipfile/control02.ctl’

*.db_file_name_convert=(‘/data2/prod’,’/data2/cipfile’)

*.log_file_name_convert=(‘/data2/prod’,’/data2/cipfile’)

10. Create password file in
$ORACLE_HOME/dbs directory

/data1/oracle11g/product/dbs

[oracle@Netsoftmate1 dbs]$ orapwd file=orapwcipfile
password=ora123

11. Start
the instance in no mount stage.

[oracle@Netsoftmate1 dbs]$ export ORACLE_SID=cipfile

[oracle@Netsoftmate1 dbs]$ sqlplus

SQL*Plus: Release 11.2.0.1.0 Production on Mon Apr 13
11:59:27 2015

Copyright (c) 1982, 2009, Oracle.  All rights reserved.

Enter user-name: sys as sysdba

Enter password:

Connected to an idle instance.

SQL> startup nomount

ORACLE instance started.

Total System Global Area 1152450560 bytes

Fixed Size                  2212696 bytes

Variable Size             352324776 bytes

Database Buffers          788529152 bytes

Redo Buffers                9383936 bytes

SQL> exit

Disconnected from Oracle Database 11g Enterprise
Edition Release 11.2.0.1.0 – 64bit Production

With the Partitioning, OLAP, Data Mining and Real
Application Testing options

[oracle@Netsoftmate1 dbs]$

12. Connect to
auxiliary instance via RMAN and issue the duplicate command.

[oracle@Netsoftmate1 dbs]$ echo $ORACLE_SID

cipfile

[oracle@Netsoftmate1 dbs]$ rman auxiliary sys/ora123

Recovery Manager: Release 11.2.0.1.0 – Production on
Mon Apr 13 12:03:23 2015

Copyright (c) 1982, 2009, Oracle and/or its
affiliates.  All rights reserved.

connected to auxiliary
database: CIPFILE (not mounted)

RMAN>

RMAN> DUPLICATE
TARGET DATABASE TO cipfile BACKUP LOCATION ‘/backup/rman_backup’;

Starting Duplicate Db at 13-APR-15

contents of Memory Script:

{

   sql clone
“create spfile from memory”;

}

executing Memory Script

sql statement: create spfile from memory

contents of Memory Script:

{

   shutdown
clone immediate;

   startup
clone nomount;

}

executing Memory Script

Oracle instance shut down

connected to auxiliary database (not started)

Oracle instance started

Total System Global Area    1152450560 bytes

Fixed Size                     2212696 bytes

Variable Size                335547560 bytes

Database Buffers             805306368 bytes

Redo Buffers                   9383936 bytes

contents of Memory Script:

{

   sql clone
“alter system set  db_name =

 ”PROD”
comment=

 ”Modified by
RMAN duplicate” scope=spfile”;

   sql clone
“alter system set  db_unique_name =

 ”CIPFILE”
comment=

 ”Modified by
RMAN duplicate” scope=spfile”;

   shutdown
clone immediate;

   startup
clone force nomount

   restore
clone primary controlfile from
‘/backup/rman_backup/controlfile_c-284539893-20150413-00’;

   alter clone
database mount;

}

executing Memory Script

sql statement: alter system set  db_name =
”PROD” comment= ”Modified by RMAN duplicate” scope=spfile

sql statement: alter system set  db_unique_name =  ”CIPFILE” comment= ”Modified by RMAN
duplicate” scope=spfile

Oracle instance shut down

Oracle instance started

Total System Global Area    1152450560 bytes

Fixed Size                     2212696 bytes

Variable Size                335547560 bytes

Database Buffers             805306368 bytes

Redo Buffers                   9383936 bytes

Starting restore at 13-APR-15

allocated channel: ORA_AUX_DISK_1

channel ORA_AUX_DISK_1: SID=63 device type=DISK

channel ORA_AUX_DISK_1: restoring control file

channel ORA_AUX_DISK_1: restore complete, elapsed
time: 00:00:03

output file name=/data2/cipfile/control01.ctl

output file name=/data2/cipfile/control02.ctl

Finished restore at 13-APR-15

database mounted

released channel: ORA_AUX_DISK_1

allocated channel: ORA_AUX_DISK_1

channel ORA_AUX_DISK_1: SID=63 device type=DISK

contents of Memory Script:

{

   set until
scn  5176531;

   set newname
for datafile  1 to

 “/data2/cipfile/system01.dbf”;

   set newname
for datafile  2 to

 “/data2/cipfile/sysaux01.dbf”;

   set newname
for datafile  3 to

 “/data2/cipfile/undotbs01.dbf”;

   set newname
for datafile  4 to

 “/data2/cipfile/users01.dbf”;

   set newname
for datafile  5 to

 “/data2/cipfile/example01.dbf”;

   set newname
for datafile  6 to

 “/data2/cipfile/data01.dbf”;

   set newname
for datafile  7 to

 “/data2/cipfile/test01.dbf”;

   set newname
for datafile  8 to

 “/data2/cipfile/tools01.dbf”;

   restore

   clone database

   ;

}

executing Memory Script

executing command: SET until clause

executing command: SET NEWNAME

executing command: SET NEWNAME

executing command: SET NEWNAME

executing command: SET NEWNAME

executing command: SET NEWNAME

executing command: SET NEWNAME

executing command: SET NEWNAME

executing command: SET NEWNAME

Starting restore at 13-APR-15

using channel ORA_AUX_DISK_1

channel ORA_AUX_DISK_1: starting datafile backup set
restore

channel ORA_AUX_DISK_1: specifying datafile(s) to
restore from backup set

channel ORA_AUX_DISK_1: restoring datafile 00001 to
/data2/cipfile/system01.dbf

channel ORA_AUX_DISK_1: restoring datafile 00002 to
/data2/cipfile/sysaux01.dbf

channel ORA_AUX_DISK_1: restoring datafile 00003 to
/data2/cipfile/undotbs01.dbf

channel ORA_AUX_DISK_1: restoring datafile 00004 to
/data2/cipfile/users01.dbf

channel ORA_AUX_DISK_1: restoring datafile 00005 to
/data2/cipfile/example01.dbf

channel ORA_AUX_DISK_1: restoring datafile 00006 to
/data2/cipfile/data01.dbf

channel ORA_AUX_DISK_1: restoring datafile 00007 to
/data2/cipfile/test01.dbf

channel ORA_AUX_DISK_1: restoring datafile 00008 to
/data2/cipfile/tools01.dbf

channel ORA_AUX_DISK_1: reading from backup piece
/backup/rman_backup/db_arch_2vq495ua_1_1.bkp

channel ORA_AUX_DISK_1: piece
handle=/backup/rman_backup/db_arch_2vq495ua_1_1.bkp tag=TAG20150413T101538

channel ORA_AUX_DISK_1: restored backup piece 1

channel ORA_AUX_DISK_1: restore complete, elapsed
time: 00:00:45

Finished restore at 13-APR-15

contents of Memory Script:

{

   switch clone
datafile all;

}

executing Memory Script

datafile 1 switched to datafile copy

input datafile copy RECID=9 STAMP=876917132 file
name=/data2/cipfile/system01.dbf

datafile 2 switched to datafile copy

input datafile copy RECID=10 STAMP=876917133 file
name=/data2/cipfile/sysaux01.dbf

datafile 3 switched to datafile copy

input datafile copy RECID=11 STAMP=876917134 file
name=/data2/cipfile/undotbs01.dbf

datafile 4 switched to datafile copy

input datafile copy RECID=12 STAMP=876917134 file
name=/data2/cipfile/users01.dbf

datafile 5 switched to datafile copy

input datafile copy RECID=13 STAMP=876917135 file
name=/data2/cipfile/example01.dbf

datafile 6 switched to datafile copy

input datafile copy RECID=14 STAMP=876917136 file
name=/data2/cipfile/data01.dbf

datafile 7 switched to datafile copy

input datafile copy RECID=15 STAMP=876917137 file
name=/data2/cipfile/test01.dbf

datafile 8 switched to datafile copy

input datafile copy RECID=16 STAMP=876917138 file
name=/data2/cipfile/tools01.dbf

contents of Memory Script:

{

   set until
scn  5176531;

   recover

   clone
database

    delete
archivelog

   ;

}

executing Memory Script

executing command: SET until clause

Starting recover at 13-APR-15

using channel ORA_AUX_DISK_1

starting media recovery

channel ORA_AUX_DISK_1: starting archived log restore
to default destination

channel ORA_AUX_DISK_1: restoring archived log

archived log thread=1 sequence=154

channel ORA_AUX_DISK_1: reading from backup piece
/backup/rman_backup/db_arch_30q49603_1_1.bkp

channel ORA_AUX_DISK_1: piece
handle=/backup/rman_backup/db_arch_30q49603_1_1.bkp tag=TAG20150413T101635

channel ORA_AUX_DISK_1: restored backup piece 1

channel ORA_AUX_DISK_1: restore complete, elapsed
time: 00:00:01

archived log file name=/backup/archive/1_154_872701561.dbf
thread=1 sequence=154

channel clone_default: deleting archived log(s)

archived log file
name=/backup/archive/1_154_872701561.dbf RECID=1 STAMP=876917145

media recovery complete, elapsed time: 00:00:04

Finished recover at 13-APR-15

contents of Memory Script:

{

   shutdown
clone immediate;

   startup
clone nomount;

   sql clone
“alter system set  db_name =

 ”CIPFILE”
comment=

 ”Reset to
original value by RMAN” scope=spfile”;

   sql clone
“alter system reset  db_unique_name
scope=spfile”;

   shutdown
clone immediate;

   startup
clone nomount;

}

executing Memory Script

database dismounted

Oracle instance shut down

connected to auxiliary database (not started)

Oracle instance started

Total System Global Area    1152450560 bytes

Fixed Size
              2212696 bytes

Variable Size                335547560 bytes

Database Buffers             805306368 bytes

Redo Buffers                   9383936 bytes

sql statement: alter system set  db_name =
”CIPFILE” comment= ”Reset to original value by RMAN” scope=spfile

sql statement: alter system reset  db_unique_name scope=spfile

Oracle instance shut down

connected to auxiliary database (not started)

Oracle instance started

Total System Global Area    1152450560 bytes

Fixed Size                     2212696 bytes

Variable Size                335547560 bytes

Database Buffers             805306368 bytes

Redo Buffers                   9383936 bytes

sql statement: CREATE CONTROLFILE REUSE SET DATABASE
“CIPFILE” RESETLOGS ARCHIVELOG


MAXLOGFILES     16


MAXLOGMEMBERS      3


MAXDATAFILES      100


MAXINSTANCES     8


MAXLOGHISTORY      292

 LOGFILE

  GROUP  1 ( ‘/data2/cipfile/redo01.log’ ) SIZE 50
M  REUSE,

  GROUP  2 ( ‘/data2/cipfile/redo02.log’ ) SIZE 50
M  REUSE,

  GROUP  3 ( ‘/data2/cipfile/redo03.log’ ) SIZE 50
M  REUSE

 DATAFILE


‘/data2/cipfile/system01.dbf’

 CHARACTER SET
WE8MSWIN1252

contents of Memory Script:

{

   set newname
for tempfile  1 to

 “/data2/cipfile/temp01.dbf”;

   switch clone
tempfile all;

   catalog
clone datafilecopy
“/data2/cipfile/sysaux01.dbf”,

 “/data2/cipfile/undotbs01.dbf”,

 “/data2/cipfile/users01.dbf”,

 “/data2/cipfile/example01.dbf”,

 “/data2/cipfile/data01.dbf”,

 “/data2/cipfile/test01.dbf”,

 “/data2/cipfile/tools01.dbf”;

   switch clone
datafile all;

}

executing Memory Script

executing command: SET NEWNAME

renamed tempfile 1 to /data2/cipfile/temp01.dbf in
control file

cataloged datafile copy

datafile copy file name=/data2/cipfile/sysaux01.dbf
RECID=1 STAMP=876917170

cataloged datafile copy

datafile copy file name=/data2/cipfile/undotbs01.dbf
RECID=2 STAMP=876917170

cataloged datafile copy

datafile copy file name=/data2/cipfile/users01.dbf
RECID=3 STAMP=876917171

cataloged datafile copy

datafile copy file name=/data2/cipfile/example01.dbf
RECID=4 STAMP=876917171

cataloged datafile copy

datafile copy file name=/data2/cipfile/data01.dbf
RECID=5 STAMP=876917172

cataloged datafile copy

datafile copy file name=/data2/cipfile/test01.dbf
RECID=6 STAMP=876917172

cataloged datafile copy

datafile copy file name=/data2/cipfile/tools01.dbf
RECID=7 STAMP=876917173

datafile 2 switched to datafile copy

input datafile copy RECID=1 STAMP=876917170 file
name=/data2/cipfile/sysaux01.dbf

datafile 3 switched to datafile copy

input datafile copy RECID=2 STAMP=876917170 file name=/data2/cipfile/undotbs01.dbf

datafile 4 switched to datafile copy

input datafile copy RECID=3 STAMP=876917171 file
name=/data2/cipfile/users01.dbf

datafile 5 switched to datafile copy

input datafile copy RECID=4 STAMP=876917171 file
name=/data2/cipfile/example01.dbf

datafile 6 switched to datafile copy

input datafile copy RECID=5 STAMP=876917172 file
name=/data2/cipfile/data01.dbf

datafile 7 switched to datafile copy

input datafile copy RECID=6 STAMP=876917172 file
name=/data2/cipfile/test01.dbf

datafile 8 switched to datafile copy

input datafile copy RECID=7 STAMP=876917173 file
name=/data2/cipfile/tools01.dbf

contents of Memory Script:

{

   Alter clone
database open resetlogs;

}

executing Memory Script

database opened

Finished Duplicate Db at 13-APR-15

RMAN>

Conclusion
In the preceding scenario based article, we have learned that backup based duplication using Rman utility with different database name and different directory structure, using db_file_name_convert and log_file_name_convert option in pfile

BY
Name: Mirza Hidayathullah Baig
Designation: Senior Database Engineer
Organization: Netsoftmate IT Solutions.
Email: info@netsoftmate.com

Comments

Leave a Reply

Your email address will not be published. Required fields are marked *

More posts
