Rman Targetless duplication with same DB name and same directory structure
Overview
Oracle Recovery Manager (RMAN) provides a comprehensive foundation for efficiently backing up and recovering the Oracle databases, it provides a common interface, via command line and Enterprise Manager, for backup tasks across different host operating systems, automates administration of your backup strategies.
Backup-based duplication uses an RMAN backup of the target (source) database as its source to create the data files in the auxiliary (destination) environment.
No connection to the target database is required. This is referred to as targetless duplication. This technique only requires a connection to the auxiliary database. Targetless duplication is available in Oracle 11g release 2 and higher.
The big advantage to backup based duplication is that if you work in an environment where it’s not possible to have a simultaneous connection to both the target and the auxiliary database you can still duplicate a database provided you can copy an RMAN backup to the auxiliary database
Server (or provided the backup is on network-mounted storage readable from the auxiliary server). In many environments, due to security rules, there is no network connectivity allowed from test environments to the production server.
In this scenario we have same database name and same directory structure.
Environment Details
Pre-requisites:
1. export Oracle sid.
2. Connect to target database via RMAN.
3. Issue the following command to initiate backup. Before issue the backup command check the backup location is sat correctly.
4. Create pfile and copy to destination server.
create directory structure to accommodate rman backup pieces on destination server and start copy.
5. Copy rman backup from target to destination server.
Steps on destination server
6. Create directory structure same as target (source) database.
7. Start the instance in nomount stage.
8. Connect to auxiliary instance via RMAN
9. Issue the following command to duplicate database with same name and same directory structure.
Conclusion
In the above article, we have learned that backup based duplication using Rman utility with same database name and same directory structure, we can refer this as targetless duplication, where no connectivity between target and auxiliary instance is required.
BY
Name: Omer
Designation: Senior Database Engineer
Organization: Netsoftmate IT Solutions.
Contact us: info@netsoftmate.com
Oracle Recovery Manager (RMAN) provides a comprehensive foundation for efficiently backing up and recovering the Oracle databases, it provides a common interface, via command line and Enterprise Manager, for backup tasks across different host operating systems, automates administration of your backup strategies.
Backup-based duplication uses an RMAN backup of the target (source) database as its source to create the data files in the auxiliary (destination) environment.
No connection to the target database is required. This is referred to as targetless duplication. This technique only requires a connection to the auxiliary database. Targetless duplication is available in Oracle 11g release 2 and higher.
The big advantage to backup based duplication is that if you work in an environment where it’s not possible to have a simultaneous connection to both the target and the auxiliary database you can still duplicate a database provided you can copy an RMAN backup to the auxiliary database
Server (or provided the backup is on network-mounted storage readable from the auxiliary server). In many environments, due to security rules, there is no network connectivity allowed from test environments to the production server.
In this scenario we have same database name and same directory structure.
Environment Details
Database Name
|
prod
|
Hostname
|
Nsmprod
|
Ip Address
|
172.16.110.18
|
OS
|
Linux
|
Version
|
x86_64
|
Datafile Location
|
/data2/prod
|
Backup Location
|
/backup/rman_backup
|
Destination details:
Database Name
|
prod
|
Hostname
|
Nsmstg
|
Ip Address
|
172.16.110.16
|
OS
|
Linux
|
Version
|
x86_64
|
Datafile Location
|
/data2/prod
|
Backup Location
|
/backup/rman_backup
|
Pre-requisites:
- Password file from target database.
- Sqlnet.ora should have correct parameters.
- Target database should be running through spfile.
1. export Oracle sid.
[oracle@Nsmprod dbs]$
hostname
Nsmprod
[oracle@Nsmprod dbs]$ export
ORACLE_SID=prod
2. Connect to target database via RMAN.
[oracle@Nsmprod dbs]$ rman
target sys/oracle
Recovery Manager: Release
11.2.0.1.0 – Production on Thu Apr 9 10:47:41 2015
Copyright (c) 1982, 2009,
Oracle and/or its affiliates. All rights
reserved.
connected to target
database: PROD (DBID=284539893)
RMAN>
RMAN> show all;
RMAN configuration
parameters for database with db_unique_name PROD are:
CONFIGURE RETENTION POLICY
TO REDUNDANCY 1; # default
CONFIGURE BACKUP
OPTIMIZATION OFF; # default
CONFIGURE DEFAULT DEVICE
TYPE TO DISK; # default
CONFIGURE CONTROLFILE
AUTOBACKUP ON;
CONFIGURE
CONTROLFILE AUTOBACKUP FORMAT FOR DEVICE TYPE DISK TO
‘/backup/rman_backup/controlfile_%F’;
CONFIGURE DEVICE TYPE DISK
PARALLELISM 1 BACKUP TYPE TO BACKUPSET; # default
CONFIGURE DATAFILE BACKUP
COPIES FOR DEVICE TYPE DISK TO 1; # default
CONFIGURE ARCHIVELOG BACKUP
COPIES FOR DEVICE TYPE DISK TO 1; # default
CONFIGURE
CHANNEL DEVICE TYPE DISK FORMAT
‘/backup/rman_backup/db_arch_%U.bkp’;
CONFIGURE MAXSETSIZE TO
UNLIMITED; # default
CONFIGURE ENCRYPTION FOR
DATABASE OFF; # default
CONFIGURE ENCRYPTION
ALGORITHM ‘AES128’; # default
CONFIGURE COMPRESSION
ALGORITHM ‘BASIC’ AS OF RELEASE ‘DEFAULT’ OPTIMIZE FOR LOAD TRUE ; # default
CONFIGURE ARCHIVELOG
DELETION POLICY TO NONE; # default
CONFIGURE SNAPSHOT
CONTROLFILE NAME TO ‘/data2/app/oracle/product/11.2.0/dbs/snapcf_prod.f’; #
default
RMAN>
RMAN> list backup;
specification does not match
any backup in the repository
RMAN>
backup database plus archivelog;
Starting backup at 10-APR-15
current log archived
using channel ORA_DISK_1
channel ORA_DISK_1: starting
archived log backup set
channel ORA_DISK_1:
specifying archived log(s) in backup set
input archived log thread=1
sequence=90 RECID=86 STAMP=875202890
input archived log thread=1
sequence=91 RECID=87 STAMP=875225400
input archived log thread=1
sequence=92 RECID=88 STAMP=875253619
input archived log thread=1
sequence=93 RECID=89 STAMP=875287426
input archived log thread=1
sequence=94 RECID=90 STAMP=875311887
input archived log thread=1
sequence=95 RECID=91 STAMP=875338210
input archived log thread=1
sequence=96 RECID=92 STAMP=875371700
input archived log thread=1
sequence=97 RECID=93 STAMP=875398375
input archived log thread=1
sequence=98 RECID=94 STAMP=875422534
input archived log thread=1
sequence=99 RECID=95 STAMP=875455916
input archived log thread=1
sequence=100 RECID=96 STAMP=875489442
input archived log thread=1
sequence=101 RECID=97 STAMP=875511892
input archived log thread=1
sequence=102 RECID=98 STAMP=875532973
input archived log thread=1
sequence=103 RECID=99 STAMP=875566589
input archived log thread=1
sequence=104 RECID=100 STAMP=875598381
input archived log thread=1
sequence=105 RECID=101 STAMP=875617253
input archived log thread=1
sequence=106 RECID=102 STAMP=875650222
input archived log thread=1
sequence=107 RECID=103 STAMP=875683804
input archived log thread=1
sequence=108 RECID=104 STAMP=875692844
input archived log thread=1
sequence=109 RECID=105 STAMP=875726521
input archived log thread=1
sequence=110 RECID=106 STAMP=875759423
input archived log thread=1
sequence=111 RECID=107 STAMP=875771364
input archived log thread=1
sequence=112 RECID=108 STAMP=875804400
input archived log thread=1
sequence=113 RECID=109 STAMP=875809288
input archived log thread=1
sequence=114 RECID=110 STAMP=875842252
input archived log thread=1
sequence=115 RECID=111 STAMP=875857844
input archived log thread=1
sequence=116 RECID=112 STAMP=875883160
input archived log thread=1
sequence=117 RECID=113 STAMP=875939543
input archived log thread=1
sequence=118 RECID=114 STAMP=875955632
input archived log thread=1
sequence=119 RECID=115 STAMP=875960595
input archived log thread=1
sequence=120 RECID=116 STAMP=876018651
input archived log thread=1
sequence=121 RECID=117 STAMP=876036137
input archived log thread=1
sequence=122 RECID=118 STAMP=876094207
input archived log thread=1
sequence=123 RECID=119 STAMP=876117455
input archived log thread=1
sequence=124 RECID=120 STAMP=876173429
input archived log thread=1
sequence=125 RECID=121 STAMP=876203937
input archived log thread=1
sequence=126 RECID=122 STAMP=876259857
input archived log thread=1
sequence=127 RECID=123 STAMP=876288622
input archived log thread=1
sequence=128 RECID=124 STAMP=876308432
input archived log thread=1
sequence=129 RECID=125 STAMP=876364250
input archived log thread=1
sequence=130 RECID=126 STAMP=876378605
input archived log thread=1
sequence=131 RECID=127 STAMP=876398550
input archived log thread=1
sequence=132 RECID=128 STAMP=876399532
input archived log thread=1
sequence=133 RECID=129 STAMP=876419413
input archived log thread=1
sequence=134 RECID=130 STAMP=876421079
input archived log thread=1
sequence=135 RECID=131 STAMP=876461598
input archived log thread=1
sequence=136 RECID=132 STAMP=876504610
input archived log thread=1
sequence=137 RECID=133 STAMP=876548085
input archived log thread=1
sequence=138 RECID=134 STAMP=876567056
input archived log thread=1
sequence=139 RECID=135 STAMP=876567230
input archived log thread=1
sequence=140 RECID=136 STAMP=876583581
input archived log thread=1
sequence=141 RECID=137 STAMP=876583754
input archived log thread=1
sequence=142 RECID=138 STAMP=876586722
input archived log thread=1
sequence=143 RECID=139 STAMP=876586874
input archived log thread=1
sequence=144 RECID=140 STAMP=876641790
input archived log thread=1
sequence=145 RECID=141 STAMP=876670700
channel ORA_DISK_1: starting
piece 1 at 10-APR-15
channel ORA_DISK_1: finished
piece 1 at 10-APR-15
piece
handle=/backup/rman_backup/db_arch_2qq41rnc_1_1.bkp tag=TAG20150410T153820
comment=NONE
channel ORA_DISK_1: backup
set complete, elapsed time: 00:01:35
Finished backup at 10-APR-15
Starting backup at 10-APR-15
using channel ORA_DISK_1
channel ORA_DISK_1: starting
full datafile backup set
channel ORA_DISK_1:
specifying datafile(s) in backup set
input datafile file
number=00001 name=/data2/prod/system01.dbf
input datafile file
number=00002 name=/data2/prod/sysaux01.dbf
input datafile file
number=00005 name=/data2/prod/example01.dbf
input datafile file
number=00003 name=/data2/prod/undotbs01.dbf
input datafile file
number=00006 name=/data2/prod/data01.dbf
input datafile file
number=00004 name=/data2/prod/users01.dbf
input datafile file
number=00007 name=/data2/prod/test01.dbf
input datafile file
number=00008 name=/data2/prod/tools01.dbf
channel ORA_DISK_1: starting
piece 1 at 10-APR-15
channel ORA_DISK_1: finished
piece 1 at 10-APR-15
piece handle=/backup/rman_backup/db_arch_2rq41rqd_1_1.bkp
tag=TAG20150410T153956 comment=NONE
channel ORA_DISK_1: backup
set complete, elapsed time: 00:01:05
Finished backup at 10-APR-15
Starting backup at 10-APR-15
current log archived
using channel ORA_DISK_1
channel ORA_DISK_1: starting
archived log backup set
channel ORA_DISK_1:
specifying archived log(s) in backup set
input archived log thread=1
sequence=146 RECID=142 STAMP=876670863
channel ORA_DISK_1: starting
piece 1 at 10-APR-15
channel ORA_DISK_1: finished
piece 1 at 10-APR-15
piece
handle=/backup/rman_backup/db_arch_2sq41rsf_1_1.bkp tag=TAG20150410T154103
comment=NONE
channel ORA_DISK_1: backup
set complete, elapsed time: 00:00:01
Finished backup at 10-APR-15
Starting Control File and
SPFILE Autobackup at 10-APR-15
piece
handle=/backup/rman_backup/controlfile_c-284539893-20150410-00 comment=NONE
Finished Control File and
SPFILE Autobackup at 10-APR-15
RMAN>
SQL> create
pfile=’/backup/rman_backup/initprod.ora’ from spfile;
File created.
[oracle@Nsmprod
rman_backup]$ scp initprod.ora
oracle@172.16.110.16:/data1/oracle11g/product/dbs/
oracle@172.16.110.16’s
password:
initprod.ora
100% 1169 1.1KB/s
00:00
[oracle@Nsmstg prod]$ mkdir
-p /backup/rman_backup/
RMAN> exit
Recovery Manager complete.
[oracle@Nsmprod
rman_backup]$ ls -lrth
total 2.8G
-rw-r—–. 1 oracle dba
1.7G Apr 10 15:39 db_arch_2qq41rnc_1_1.bkp
-rw-r—–. 1 oracle dba 1.2G
Apr 10 15:40 db_arch_2rq41rqd_1_1.bkp
-rw-r—–. 1 oracle
dba 24K Apr 10 15:41
db_arch_2sq41rsf_1_1.bkp
-rw-r—–. 1 oracle dba
9.6M Apr 10 15:41 controlfile_c-284539893-20150410-00
[oracle@Nsmprod
rman_backup]$ scp * oracle@172.16.110.16:/backup/rman_backup/
oracle@172.16.110.16’s
password:
controlfile_c-284539893-20150410-00
100% 9792KB 9.6MB/s
00:01
db_arch_2qq41rnc_1_1.bkp
100% 1668MB 11.2MB/s
02:29
db_arch_2rq41rqd_1_1.bkp
100% 1135MB 11.2MB/s
01:41
db_arch_2sq41rsf_1_1.bkp
100% 24KB
23.5KB/s 00:00
Steps on destination server
6. Create directory structure same as target (source) database.
[oracle@Nsmstg prod]$ mkdir
-p /data2/prod
[oracle@Nsmstg prod]$ mkdir
-p /backup/archive/
[oracle@Nsmstg dbs]$ export
ORACLE_SID=prod
[oracle@Nsmstg dbs]$ sqlplus
SQL*Plus: Release 11.2.0.1.0
Production on Fri Apr 10 15:58:10 2015
Copyright (c) 1982, 2009,
Oracle. All rights reserved.
Enter user-name: sys as
sysdba
Enter password:
Connected to an idle
instance.
SQL>
SQL> startup nomount
ORACLE instance started.
Total System Global Area
1152450560 bytes
Fixed Size 2212696 bytes
Variable Size 352324776 bytes
Database Buffers 788529152 bytes
Redo Buffers 9383936 bytes
SQL> exit
Disconnected from Oracle
Database 11g Enterprise Edition Release 11.2.0.1.0 – 64bit Production
With the Partitioning, OLAP,
Data Mining and Real Application Testing options
[oracle@Nsmstg dbs]$
[oracle@Nsmstg dbs]$ rman
auxiliary sys/oracle
Recovery Manager: Release
11.2.0.1.0 – Production on Fri Apr 10 15:59:22 2015
Copyright (c) 1982, 2009,
Oracle and/or its affiliates. All rights
reserved.
connected to auxiliary
database: PROD (not mounted)
RMAN>
RMAN>
duplicate database to prod backup location ‘/backup/rman_backup’ nofilenamecheck;
Starting Duplicate Db at
10-APR-15
contents of Memory Script:
{
sql clone “create spfile from
memory”;
}
executing Memory Script
sql statement: create spfile
from memory
contents of Memory Script:
{
shutdown clone immediate;
startup clone nomount;
}
executing Memory Script
Oracle instance shut down
connected to auxiliary
database (not started)
Oracle instance started
Total System Global
Area 1152450560 bytes
Fixed Size 2212696 bytes
Variable Size 335547560 bytes
Database Buffers 805306368 bytes
Redo Buffers 9383936 bytes
contents of Memory Script:
{
sql clone “alter system set db_name =
”PROD” comment=
”Modified by RMAN duplicate”
scope=spfile”;
sql clone “alter system set db_unique_name =
”PROD” comment=
”Modified by RMAN duplicate”
scope=spfile”;
shutdown clone immediate;
startup clone force nomount
restore clone primary controlfile from
‘/backup/rman_backup/controlfile_c-284539893-20150410-00’;
alter clone database mount;
}
executing Memory Script
sql statement: alter system
set db_name = ”PROD” comment= ”Modified by RMAN
duplicate” scope=spfile
sql statement: alter system
set db_unique_name = ”PROD” comment= ”Modified by RMAN
duplicate” scope=spfile
Oracle instance shut down
Oracle instance started
Total System Global
Area 1152450560 bytes
Fixed Size 2212696 bytes
Variable Size 335547560 bytes
Database Buffers 805306368 bytes
Redo Buffers 9383936 bytes
Starting restore at
10-APR-15
allocated channel:
ORA_AUX_DISK_1
channel ORA_AUX_DISK_1:
SID=63 device type=DISK
channel ORA_AUX_DISK_1:
restoring control file
channel ORA_AUX_DISK_1:
restore complete, elapsed time: 00:00:03
output file
name=/data2/prod/control01.ctl
output file
name=/data2/prod/control02.ctl
Finished restore at
10-APR-15
database mounted
released channel:
ORA_AUX_DISK_1
allocated channel:
ORA_AUX_DISK_1
channel ORA_AUX_DISK_1: SID=63
device type=DISK
contents of Memory Script:
{
set until scn 5022379;
set newname for datafile 1 to
“/data2/prod/system01.dbf”;
set newname for datafile 2 to
“/data2/prod/sysaux01.dbf”;
set newname for datafile 3 to
“/data2/prod/undotbs01.dbf”;
set newname for datafile 4 to
“/data2/prod/users01.dbf”;
set newname for datafile 5 to
“/data2/prod/example01.dbf”;
set newname for datafile 6 to
“/data2/prod/data01.dbf”;
set newname for datafile 7 to
“/data2/prod/test01.dbf”;
set newname for datafile 8 to
“/data2/prod/tools01.dbf”;
restore
clone database
;
}
executing Memory Script
executing command: SET until
clause
executing command: SET
NEWNAME
executing command: SET
NEWNAME
executing command: SET NEWNAME
executing command: SET
NEWNAME
executing command: SET
NEWNAME
executing command: SET
NEWNAME
executing command: SET
NEWNAME
executing command: SET
NEWNAME
Starting restore at
10-APR-15
using channel ORA_AUX_DISK_1
channel ORA_AUX_DISK_1:
starting datafile backup set restore
channel ORA_AUX_DISK_1:
specifying datafile(s) to restore from backup set
channel ORA_AUX_DISK_1:
restoring datafile 00001 to /data2/prod/system01.dbf
channel ORA_AUX_DISK_1:
restoring datafile 00002 to /data2/prod/sysaux01.dbf
channel ORA_AUX_DISK_1:
restoring datafile 00003 to /data2/prod/undotbs01.dbf
channel ORA_AUX_DISK_1:
restoring datafile 00004 to /data2/prod/users01.dbf
channel ORA_AUX_DISK_1:
restoring datafile 00005 to /data2/prod/example01.dbf
channel ORA_AUX_DISK_1:
restoring datafile 00006 to /data2/prod/data01.dbf
channel ORA_AUX_DISK_1:
restoring datafile 00007 to /data2/prod/test01.dbf
channel ORA_AUX_DISK_1:
restoring datafile 00008 to /data2/prod/tools01.dbf
channel ORA_AUX_DISK_1:
reading from backup piece /backup/rman_backup/db_arch_2rq41rqd_1_1.bkp
channel ORA_AUX_DISK_1:
piece handle=/backup/rman_backup/db_arch_2rq41rqd_1_1.bkp
tag=TAG20150410T153956
channel ORA_AUX_DISK_1:
restored backup piece 1
channel ORA_AUX_DISK_1:
restore complete, elapsed time: 00:00:35
Finished restore at
10-APR-15
contents of Memory Script:
{
switch clone datafile all;
}
executing Memory Script
datafile 1 switched to
datafile copy
input datafile copy RECID=1
STAMP=876672089 file name=/data2/prod/system01.dbf
datafile 2 switched to
datafile copy
input datafile copy RECID=2
STAMP=876672089 file name=/data2/prod/sysaux01.dbf
datafile 3 switched to
datafile copy
input datafile copy RECID=3
STAMP=876672090 file name=/data2/prod/undotbs01.dbf
datafile 4 switched to
datafile copy
input datafile copy RECID=4
STAMP=876672090 file name=/data2/prod/users01.dbf
datafile 5 switched to
datafile copy
input datafile copy RECID=5
STAMP=876672090 file name=/data2/prod/example01.dbf
datafile 6 switched to
datafile copy
input datafile copy RECID=6
STAMP=876672091 file name=/data2/prod/data01.dbf
datafile 7 switched to
datafile copy
input datafile copy RECID=7
STAMP=876672091 file name=/data2/prod/test01.dbf
datafile 8 switched to
datafile copy
input datafile copy RECID=8
STAMP=876672091 file name=/data2/prod/tools01.dbf
contents of Memory Script:
{
set until scn 5022379;
recover
clone database
delete archivelog
;
}
executing Memory Script
executing command: SET until
clause
Starting recover at
10-APR-15
using channel ORA_AUX_DISK_1
starting media recovery
channel ORA_AUX_DISK_1:
starting archived log restore to default destination
channel ORA_AUX_DISK_1:
restoring archived log
archived log thread=1
sequence=146
channel ORA_AUX_DISK_1:
reading from backup piece /backup/rman_backup/db_arch_2sq41rsf_1_1.bkp
channel ORA_AUX_DISK_1:
piece handle=/backup/rman_backup/db_arch_2sq41rsf_1_1.bkp
tag=TAG20150410T154103
channel ORA_AUX_DISK_1:
restored backup piece 1
channel ORA_AUX_DISK_1:
restore complete, elapsed time: 00:00:01
archived log file
name=/backup/archive/1_146_872701561.dbf thread=1 sequence=146
channel clone_default:
deleting archived log(s)
archived log file
name=/backup/archive/1_146_872701561.dbf RECID=1 STAMP=876672098
media recovery complete,
elapsed time: 00:00:04
Finished recover at
10-APR-15
contents of Memory Script:
{
shutdown clone immediate;
startup clone nomount;
sql clone “alter system set db_name =
”PROD” comment=
”Reset to original value by RMAN”
scope=spfile”;
sql clone “alter system reset db_unique_name scope=spfile”;
shutdown clone immediate;
startup clone nomount;
}
executing Memory Script
database dismounted
Oracle instance shut down
connected to auxiliary
database (not started)
Oracle instance started
Total System Global
Area 1152450560 bytes
Fixed Size 2212696 bytes
Variable Size 335547560 bytes
Database Buffers 805306368 bytes
Redo Buffers 9383936 bytes
sql statement: alter system
set db_name = ”PROD” comment= ”Reset to original value
by RMAN” scope=spfile
sql statement: alter system
reset db_unique_name scope=spfile
Oracle instance shut down
connected to auxiliary
database (not started)
Oracle instance started
Total System Global
Area 1152450560 bytes
Fixed Size 2212696 bytes
Variable Size 335547560 bytes
Database Buffers 805306368 bytes
Redo Buffers 9383936 bytes
sql statement: CREATE
CONTROLFILE REUSE SET DATABASE “PROD” RESETLOGS ARCHIVELOG
MAXLOGFILES 16
MAXLOGMEMBERS 3
MAXDATAFILES 100
MAXINSTANCES 8
MAXLOGHISTORY 292
LOGFILE
GROUP
1 ( ‘/data2/prod/redo01.log’ ) SIZE 50 M
REUSE,
GROUP
2 ( ‘/data2/prod/redo02.log’ ) SIZE 50 M
REUSE,
GROUP
3 ( ‘/data2/prod/redo03.log’ ) SIZE 50 M
REUSE
DATAFILE
‘/data2/prod/system01.dbf’
CHARACTER SET WE8MSWIN1252
contents of Memory Script:
{
set newname for tempfile 1 to
“/data2/prod/temp01.dbf”;
switch clone tempfile all;
catalog clone datafilecopy “/data2/prod/sysaux01.dbf”,
“/data2/prod/undotbs01.dbf”,
“/data2/prod/users01.dbf”,
“/data2/prod/example01.dbf”,
“/data2/prod/data01.dbf”,
“/data2/prod/test01.dbf”,
“/data2/prod/tools01.dbf”;
switch clone datafile all;
}
executing Memory Script
executing command: SET
NEWNAME
renamed tempfile 1 to
/data2/prod/temp01.dbf in control file
cataloged datafile copy
datafile copy file
name=/data2/prod/sysaux01.dbf RECID=1 STAMP=876672123
cataloged datafile copy
datafile copy file name=/data2/prod/undotbs01.dbf
RECID=2 STAMP=876672123
cataloged datafile copy
datafile copy file
name=/data2/prod/users01.dbf RECID=3 STAMP=876672124
cataloged datafile copy
datafile copy file
name=/data2/prod/example01.dbf RECID=4 STAMP=876672124
cataloged datafile copy
datafile copy file
name=/data2/prod/data01.dbf RECID=5 STAMP=876672125
cataloged datafile copy
datafile copy file
name=/data2/prod/test01.dbf RECID=6 STAMP=876672125
cataloged datafile copy
datafile copy file
name=/data2/prod/tools01.dbf RECID=7 STAMP=876672125
datafile 2 switched to
datafile copy
input datafile copy RECID=1
STAMP=876672123 file name=/data2/prod/sysaux01.dbf
datafile 3 switched to
datafile copy
input datafile copy RECID=2
STAMP=876672123 file name=/data2/prod/undotbs01.dbf
datafile 4 switched to
datafile copy
input datafile copy RECID=3
STAMP=876672124 file name=/data2/prod/users01.dbf
datafile 5 switched to
datafile copy
input datafile copy RECID=4
STAMP=876672124 file name=/data2/prod/example01.dbf
datafile 6 switched to
datafile copy
input datafile copy RECID=5
STAMP=876672125 file name=/data2/prod/data01.dbf
datafile 7 switched to
datafile copy
input datafile copy RECID=6
STAMP=876672125 file name=/data2/prod/test01.dbf
datafile 8 switched to
datafile copy
input datafile copy RECID=7
STAMP=876672125 file name=/data2/prod/tools01.dbf
contents of Memory Script:
{
Alter clone database open resetlogs;
}
executing Memory Script
database opened
Finished Duplicate Db at
10-APR-15
RMAN>
RMAN> exit
Recovery Manager complete.
[oracle@Nsmstg dbs]$ sqlplus
SQL*Plus: Release 11.2.0.1.0
Production on Fri Apr 10 16:04:05 2015
Copyright (c) 1982, 2009,
Oracle. All rights reserved.
Enter user-name: sys as
sysdba
Enter password:
Connected to:
Oracle Database 11g
Enterprise Edition Release 11.2.0.1.0 – 64bit Production
With the Partitioning, OLAP,
Data Mining and Real Application Testing options
SQL> select
name,open_mode from v$database;
NAME OPEN_MODE
———
——————–
PROD READ WRITE
SQL> select host_name from
v$instance;
HOST_NAME
—————————————————————-
Nsmstg
SQL> select
tablespace_name,status from dba_tablespaces;
TABLESPACE_NAME STATUS
——————————
———
SYSTEM ONLINE
SYSAUX ONLINE
UNDOTBS1 ONLINE
TEMP ONLINE
USERS ONLINE
EXAMPLE ONLINE
DATA ONLINE
TEST ONLINE
TOOLS ONLINE
9 rows selected.
Conclusion
In the above article, we have learned that backup based duplication using Rman utility with same database name and same directory structure, we can refer this as targetless duplication, where no connectivity between target and auxiliary instance is required.
BY
Name: Omer
Designation: Senior Database Engineer
Organization: Netsoftmate IT Solutions.
Contact us: info@netsoftmate.com
