Overview:
At times standby database can go out of Sync for many reasons like, accidentally deleting archive log on primary or RMAN backup deleted archive log before shipping to standby database server. When this happens you must rebuild the Standby database using primary database backup.
In this article we outline the process of rebuild the Physical
Standby which is out of sync from Primary.
In this article we outline the process of rebuild the Physical
Standby which is out of sync from Primary.
Environment Details
|
Hostname
|
Primary server :–
lnx-nsm-prod01/ lnx-nsm-prod02
Standby
Server :–
lnx-nsm-dr01/ lnx-nsm-dr02
|
|
Operating
system |
Linux
|
|
Database
Environment |
NSMDB
and NSMDR |
- Take full
RMAN backup of primary. Create location if does not exists.
run {
allocate channel c1
device type disk format ‘/backup/nsmdb/NSMDB_%U’;
device type disk format ‘/backup/nsmdb/NSMDB_%U’;
backup database plus
archivelog tag=”FORSTDBY”;
archivelog tag=”FORSTDBY”;
}
- Take a
control file backup from primary.
rman target /
backup current controlfile for
standby format ‘/backup/nsmdb/NSMDB_stby_ctl’;
standby format ‘/backup/nsmdb/NSMDB_stby_ctl’;
- Copy backup pieces
to standby server. Create location if does not exists on standby
- Stop and clean
up standby Database files from locations
srvctl stop database
–d nsmdr
–d nsmdr
- Start the standby database instance in nomount
and restore the controlfile.
rman target /
startup nomount
restore standby
controlfile from ‘/backup/nsmdb/NSMDB_stby_ctl’
controlfile from ‘/backup/nsmdb/NSMDB_stby_ctl’
- Mount the standby database, stop MRP if it is up,
catalog the backup pieces.
SQL> alter database
mount standby database;
mount standby database;
SQL> ALTER DATABASE
RECOVER MANAGED STANDBY DATABASE CANCEL;
RECOVER MANAGED STANDBY DATABASE CANCEL;
rman target /
catalog start with ‘/backup/nsmdb/NSMDB_%U’;
- Now restore
database.
run {
allocate channel c1
device type disk format ‘/backup/nsmdb/NSMDB_%U’;
device type disk format ‘/backup/nsmdb/NSMDB_%U’;
restore database;
}
Exit;
- Need to shutdown
the database.
SQL> shutdown
immediate;
immediate;
- Start the
database in read only mode.
$ srvctl start database –d nsmdr
- Restart MRP
and ensure that recovery is progressing.
DGMGRL> edit database nsmdr set state=APPLY-ON;
Monitoring RMAN Progress
The below query can be used to monitor the progress of RMAN
sessions performing backup/restore.
set lines 150
col MESSAGE for a100
col sid for 999999
col ELAPSED_SECONDS
for 999999
for 999999
col TIME_REMAINING for
999999
999999
col comp for 999
heading “%Comp”
heading “%Comp”
SELECT sid, MESSAGE,
ELAPSED_SECONDS, TIME_REMAINING, round(sofar/totalwork*100) comp
ELAPSED_SECONDS, TIME_REMAINING, round(sofar/totalwork*100) comp
FROM v$session_longops
WHERE opname LIKE
‘RMAN%’
‘RMAN%’
AND opname NOT LIKE
‘%aggregate%’
‘%aggregate%’
AND totalwork != 0
AND sofar <>
totalwork;
totalwork;
Conclusion
In this article we have learnt the steps to rebuild a physical standby database which was out of sync from primary database.
In this article we have learnt the steps to rebuild a physical standby database which was out of sync from primary database.
